Kawasaki
Engine type | Liquid-cooled, 4-stroke, parallel twin |
Compression ratio | 10.8:1 |
Valve system | DOHC, 8 valves |
Bore x stroke | 83.0 mm x 60.0 mm / 3.27 in x 2.36 in |
Displacement | 649 cm³ / 39.6 in³ |
Fuel system | Fuel injection with dual throttles: 36 mm x 2 |
Lubrication | Forced lubrication, semi‑dry sump |
Starting system | Electric |
Ignition system | Digital |
Maximum power | 50.2 kW {68 PS} / 8,000 rpm |
Maximum torque | 64.0 N•m / 47.2 lb-ft {6.5 kgf•m} / 6,700 rpm |
CO2 emission | 107 g/km |
Fuel consumption | 4.4 l/100km / 53.5 mpg |
CO2 emission 35 kW kit | 107 g/km |
Fuel consumption 35 kW kit | 4.5 l/100km / 52.3 mpg |
Transmission | 6-speed, return shift |
Clutch | Wet, multi disc |
Primary reduction ratio | 2.095 (88/42) |
Gear ratios | 1st: 2.438 (39/16), 2nd: 1.714 (36/21), 3rd: 1.333 (32/24), 4th: 1.111 (30/27), 5th: 0.966 (28/29), 6th: 0.852 (23/27) |
Final drive | Sealed chain |
Final reduction ratio | 3.067 (46/15) |
Frame type | Trellis, high-tensile steel |
Trail | 100 mm / 3.94 in |
Wheel travel front | 125 mm / 4.92 in |
Wheel travel rear | 130 mm / 5.12 in |
Tyre front | 120/70 ZR17 M/C (58W) |
Tyre rear | 160/60 ZR17 M/C (69W) |
Dimensions | L: 2,055 mm / 80.91 in, W: 740 mm / 29.13 in, H: 1,145 mm / 45.08 in |
Steering angle L R | 32° / 32° |
Wheel base | 1,410 mm / 55.51 in |
Ground clearance | 130 mm / 5.12 in |
Fuel capacity | 15.0 litres / 3.96 gal |
Seat height | 790 mm / 31.10 in |
Curb mass | 193 kg / 425.5 lb |
Front brake type | Dual semi-floating petal discs |
Front brake diameter | Ø 300 mm / 11.81 in |
Front brake caliper type | Dual-piston |
Rear brake type | Single petal disc |
Rear brake diameter | Ø 220 mm / 8.66 in |
Rear brake caliper type | Single-piston |
Front suspension type | Telescopic fork |
Front suspension diameter | Ø 41 mm / 1.61 in |
Rear suspension type | Horizontal Back-link with spring preload adjustability |
