CBR600RR

CBR600RR

Honda

Engine typeLiquid cooled 16-valve DOHC, inline-4
Engine displacement599 cc
No of valves per cylinder4
Bore and stroke67 mm / 2.64" x 42.5 mm / 1.67"
Compression ratio12.2:1
Max power output89 kW / 119.37 hp at 14,250 rpm
Max torque63 Nm / 46.47 lb-ft at 11,500 rpm
Noise levelLurban 74 dB, Lwot 77 dB
Oil capacity3.4 L / 0.90 gal
CarburationPGM-FI
Fuel tank capacity18 L / 4.76 gal
Co2 emissions wmtc128 g/km
Fuel consumption5.5 L/100km / 18.2 km/L / 42.81 mpg
StarterElectric
Battery capacity12-9.1Ah YTZ10S
Clutch typeWet, multiplate hydraulic clutch
Transmission typeManual 6-speed
Final driveChain
Frame typeAluminium twin tube composite twin spar
Dimensions2,030 mm / 79.92" x 685 mm / 26.97" x 1140 mm / 44.88"
Wheelbase1,370 mm / 53.94"
Caster angle24°06’
Trail100 mm / 3.94"
Seat height820 mm / 32.28"
Ground clearance125 mm / 4.92"
Kerb weight193 kg / 425.49 lbs
Turning radius3.2 m
Suspension frontFully adjustable Showa 41 mm Big Piston USD, 120 mm stroke
Suspension rearFully adjustable Showa rear shock operating through Unit Pro-Link, 128 mm axle travel
Rim size front17 M/C x MT3.50
Rim size rear17 M/C x MT5.50
Tyres front120/70ZR17M/C DUNLOP SPORTMAX Roadsports2
Tyres rear180/55ZR17M/C DUNLOP SPORTMAX Roadsports2
Abs system type2 channel
Brakes front310 mm floating discs with radial-mount 4-piston caliper
Brakes rear220 mm disc with single piston caliper
InstrumentsTFT-LCD
HeadlightLED
TaillightLED
ConnectivityNo
UsbOptional
12v socketNo
Auto winker cancelNo
QuickshifterYes
Security systemHISS
Cruise controlNo
Cornering lightsNo
