F800GS

F800GS

BMW

Rated output64 kW (87 hp) at 6,750 rpm, OE power reduction: 35 kW (48 hp) at 5,500 rpm
Emission controlClosed-loop 3-way catalytic converter
TypeWater-cooled, 2-cylinder, four-stroke engine with four cam-operated valves per cylinder, two overhead camshafts and dry-sump lubrication
Bore x stroke86 mm x 77 mm
Capacity895 cc
Compression ratio13.1 : 1
Mixture controlElectronic intake pipe injection / digital engine management system: BMS-X with throttle-by-wire
Exhaust emission standards EUEU 5
Max torque91 Nm at 6,750 rpm, power reduction: 70 Nm at 4,500 rpm / 67 lb-ft at 6,750 rpm
Fuel consumption per 100 km based on WMTC4.3 l
Fuel typeSuper unleaded (max. 15% ethanol, E15), 95 ROZ/RON, 90 AKI
Maximum speed190 kmh (OE output reduction 35 kW: 161 km/h) / 118 mph
Co2 emission based on WMTC99 g/km
Battery12 V / 9 Ah, maintenance-free
AlternatorPermanent magnet alternator with 420 W (nominal power)
ClutchMultiplate clutch in oil bath, anti-hopping (slipper) clutch
GearboxClaw-shifted 6-speed gearbox integrated in the transmission housing
DriveEndless X-ring chain, jerk damping in the rear hub
FrameBridge-type frame, steel shell construction
Front wheel suspensionTelescopic fork, diameter 41 mm
Steering head angle63°
WheelsAluminium cast wheels
Rim front2.50 x 19"
Rim rear4.25 x 17"
Tire front110/80 R19
Tire rear150/70 R17
Brake frontTwin disc brake, floating brake discs, diameter 305 mm, 2-piston floating caliper
Brake rearSingle disc brake, diameter 265 mm, 1-piston floating caliper
AbsBMW Motorrad ABS
Castor106.1 mm / 4.17"
Wheelbase1,556 mm / 61.3"
Rear wheel suspensionAluminum twin-sided swingarm, central spring strut, rebound damping adjustable
Seat height at unladen weight815 mm (lowering: 760 mm; seat extra low: 780 mm; seat low: 790 mm; comfort seat: 830 mm; rallye seat: 845 mm) / 32.1" (OE lowering: 30"; OE seat extra low: 30.7"; OA seat low: 31.1"; OE comfort seat: 32.7"; Opt. Acc. rallye seat: 33.3")
Inner leg curve at unladen weight1,830 mm (lowering: 1,730 mm; seat extra low: 1,770 mm; seat low: 1,790 mm; comfort seat: 1,870 mm; rallye seat: 1,890 mm) / 72.0" (OE lowering: 68.1"; OE seat extra low: 69.7"; OA seat low: 70.5"; OE comfort seat: 73.7"; OA rallye seat: 74.4")
Usable tank volume15 l / 4.0 gal
Reserveapprox. 4 l / approx. 1 gal
Height1,225 mm / 48.2" (above windshield, at DIN unladen weight)
Unladen weight road ready fully fuelled227 kg / 500 lbs
Permitted total weight440 kg / 970 lbs
Payload with standard equipment213 kg / 470 lbs
Length2,296 mm / 90.3" (over license plate holder)
Width910 mm / 35.8" (without accessories)
Standard equipment6.5" TFT colour display, including BMW Motorrad Connectivity, BMW Motorrad ABS Pro, Dynamic Traction Control (DTC), RAIN/ROAD riding modes, 12 V and USB socket, Adjustable brake and clutch levers
Optional equipmentDynamic ESA, Riding modes Pro (Dynamic / Enduro), Shift assistant Pro, Keyless Ride, Tyre pressure control (RDC), Intelligent emergency call, Touring package (heated grip/daytime driving lights/hand protectors), Dynamics package (riding modes Pro/shift assistant Pro/dynamic ESA), Comfort package (cruise control/prep. for navigation system/Keyless Ride/case holder/M Endurance chain)
Optional accessoriesVario luggage system, Tank bag, Engine guard, Adjustable footbrake levers, Handlebar risers, High windscreen, BMW Motorrad ConnectedRide Navigator, and much more
