BMW
Rated output | 100 kW / 136 hp at 7,750 rpm |
Emission control | Closed-loop 3-way catalytic converter |
Type | Two-cylinder, air/liquid-cooled, four-stroke boxer engine with two overhead spur-gear driven camshafts, one counterbalance shaft and BMW ShiftCam variable intake camshaft control |
Bore stroke | 102.5 mm x 76 mm / 4.04" x 2.99" |
Capacity | 1,254 cc |
Max torque | 143 Nm at 6,250 rpm / 105.45 lb-ft |
Compression ratio | 12.5:1 |
Mixture control | Electronic intake pipe injection / digital engine management system: BMS-O with throttle-by-wire |
Exhaust emission standards | EU 5 |
Fuel consumption wmtc | 4.75 L/100 km / 49.56 mpg |
Fuel type | Super unleaded (max. 15% ethanol, E15), 95 ROZ/RON, 90 AKI |
Co2 emission wmtc | 110 g/km |
Alternator | Permanent magnet alternator with 508 W (nominal power) |
Battery | 12 V / 12 Ah, maintenance-free |
Clutch | Multiplate clutch in oil bath, anti-hopping clutch |
Gearbox | Claw-shifted 6-speed gearbox with helical gears |
Drive | Cardan |
Frame | Steel tube frame with load-bearing engine, steel tube sub-frame |
Front suspension | Upside-down telescopic fork |
Rear suspension | Cast aluminum single-sided swingarm with BMW Motorrad Paralever, WAD shock absorber, spring preload continuously adjustable hydraulically by handwheel, rebound damping adjustable by handwheel |
Suspension travel front rear | 140 mm / 140 mm / 5.51" / 5.51" |
Wheelbase | 1,512 mm / 59.53" |
Castor | 129.6 mm / 5.1" |
Steering head angle | 61.7° |
Wheels | Aluminium cast wheels |
Rim front | 3.50 x 17" |
Rim rear | 5.50 x 17" |
Tyre front | 120/70 ZR17 |
Tyre rear | 180/55 ZR17 |
Brake front | Twin disc brake, floating brake discs, Ø 320 mm / Ø 12.6", 4-piston radial brake caliper |
Brake rear | Single disc brake, Ø 276 mm / Ø 10.87", 2-piston floating caliper |
Abs | BMW Motorrad Integral ABS Pro (partial integral, lean angle optimized) |
Seat height unladen | 820 mm / 32.28" (seat low: 760 mm / 29.92"; seat sport: 840 mm / 33.07") |
Usable tank volume | 18 L / 4.76 gal |
Reserve | Approx. 4 L / 1.06 gal |
Length | 2,165 mm / 85.24" (over license plate holder) |
Height | 1,300 mm / 51.18" (above mirror, at DIN unladen weight) |
Width | 880 mm / 34.65" (above mirror) |
Unladen weight fully fuelled | 239 kg / 526.9 lbs |
Permitted total weight | 460 kg / 1,014 lbs |
Payload | 221 kg / 487.22 lbs |
Standard equipment | TFT colour display with BMW Motorrad Connectivity, Full LED headlight, Dynamic Traction Control (DTC), Integral ABS Pro (lean-optimised ABS), 3 riding modes (Eco, Rain, and Road), Hill Start Control (HSC), USB charging socket, Intelligent emergency call, Dynamic Brake Control (DBC) |
Optional equipment | Dynamic ESA (electronically adjustable chassis with load compensation and automatic damping mode), Heated seat for rider and passenger, Option 719 billet pack, Sports silencer, Pro riding modes with additional modes (Dynamic, Dynamic Pro) and preselected riding mode (customised number of selectable modes), automatic Hill Start Control (HSC Pro), and dynamic engine brake control, Adaptive headlight |
Optional accessories | Luggage system, Tank bag, Tinted windscreen, Topcase, Liner for touring case and topcase, Option 719 footrest system (adjustable), Seats in different heights, Engine protection bar |
