Kawasaki
Engine type | Liquid-cooled, 4-stroke, in-line four |
Compression ratio | 12.3:1 |
Valve system | DOHC, 16 valves |
Bore x stroke | 57.0 mm x 39.1 mm / 2.24 in x 1.54 in |
Displacement | 399 cm³ / 24.35 in³ |
Fuel system | Fuel injection: 34 mm x 4 |
Lubrication | Forced lubrication, wet sump |
Starting system | Electric |
Ignition system | Digital |
Maximum power | 57.0 kW {77 PS} / 14,500 rpm |
Maximum power with ram air | 58.7 kW {80 PS} / 14,500 rpm |
Maximum torque | 39.0 N•m {4.0 kgf•m} / 13,000 rpm / 28.77 lb-ft |
Co2 emission | 120 g/km |
Fuel consumption | 5.1 l/100km / 46.1 mpg |
Transmission | 6-speed, return shift |
Clutch | Wet, multi disc |
Primary reduction ratio | 2.029 (69/34) |
Gear ratios | 1st: 2.929 (41/14), 2nd: 2.056 (37/18), 3rd: 1.619 (34/21), 4th: 1.333 (32/24), 5th: 1.154 (30/26), 6th: 1.037 (28/27) |
Final drive | Sealed chain |
Final reduction ratio | 3.429 (48/14) |
Frame type | Trellis, high-tensile steel |
Trail | 97 mm / 3.82 in |
Wheel travel front | 120 mm / 4.72 in |
Wheel travel rear | 112 mm / 4.41 in |
Tyre front | 120/70 ZR17 M/C (58W) |
Tyre rear | 160/60 ZR17 M/C (69W) |
Dimensions l w h | 1,990 mm x 765 mm x 1,110 mm / 78.35 in x 30.12 in x 43.70 in |
Steering angle | 35° / 35° |
Wheel base | 1,380 mm / 54.33 in |
Ground clearance | 135 mm / 5.31 in |
Fuel capacity | 15.0 litres / 3.96 gal |
Seat height | 800 mm / 31.50 in |
Curb mass | 189 kg / 416.67 lbs |
Front brake type | Dual semi-floating discs |
Front brake diameter | Ø 290 mm / 11.42 in |
Front brake caliper type | Radial-mount, monobloc, opposed 4-piston |
Rear brake type | Single disc |
Rear brake diameter | Ø 220 mm / 8.66 in |
Rear brake caliper type | Single-piston |
Front suspension type | Inverted Separate Function fork (SFF-BP) with top-out springs |
Front suspension diameter | Ø 37 mm / 1.46 in |
Rear suspension type | Horizontal Back-link, gas-charged shock with spring preload adjustability |
