Ducati
Type | Superquadro: L-twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled |
Displacement | 955 cc |
Bore x stroke | 100 mm / 3.94 in x 60,8 mm / 2.39 in |
Compression ratio | 12.5:1 |
Power | 114 kW / 155 hp @ 10.750 rpm |
Torque | 104 Nm / 76.7 lb-ft @ 9.000 rpm |
Fuel injection | Electronic fuel injection system, Twin injectors per cylinder, Full ride-by-wire elliptical throttle bodies |
Exhaust | 2-1-2-1 system, 2 catalytic converters, 2 lambda probes |
Gearbox | 6 speed with Ducati Quick Shift (DQS) up/down EVO 2 |
Primary drive | Straight cut gears, Ratio 1.77:1 |
Gear ratios | 1=37/15, 2=30/16, 3=27/18, 4=25/20, 5=24/22, 6=23/24 |
Final drive | Chain, Front sprocket 15, Rear sprocket 43 |
Clutch | Hydraulically controlled slipper and self-servo wet multiplate clutch, Self bleeding master cylinder |
Frame | Monocoque Aluminium |
Front suspension | Öhlins NIX30 43 mm with TiN treatment, fully adjustable usd fork |
Front wheel | 5-spokes light alloy 3.50 in x 17 in |
Front tyre | Pirelli Diablo Rosso IV Corsa 120/70 ZR17 |
Rear suspension | Fully adjustable Öhlins TTX36 monoshock, Aluminum single-sided swingarm |
Rear wheel | 5-spokes light alloy 5.50 in x 17 in |
Rear tyre | Pirelli Diablo Rosso IV Corsa 180/60 ZR17 |
Wheel travel front rear | 120 mm / 4.72 in - 130 mm / 5.12 in |
Front brake | 2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston callipers with Bosch Cornering ABS, Self bleeding master cylinder |
Rear brake | 245 mm disc, 2-piston calliper with Bosch Cornering ABS |
Instrumentation | Digital unit, 4.3 in TFT colour display |
Wet weight no fuel | 190 kg / 419 lb |
Seat height | 835 mm / 32.9 in |
Wheelbase | 1,438 mm / 56.6 in |
Rake | 24° |
Trail | 99 mm / 3.90 in |
Fuel tank capacity | 17 l / 4.5 gal |
Number of seats | Dual seat |
Safety equipment | Riding Modes, Power Modes, Bosch Cornering ABS, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) EVO, Engine Brake Control (EBC) EVO, Auto tyre calibration |
Standard equipment | Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Öhlins steering damper, Auto-off indicators, Lithium-ion battery, Silencer outlet cover in carbon fibre and titanium, Carbon fibre components (front and rear mudguards, heel guards, swinging arm cover, chain guard, rear shock protector), Billet aluminium top triple clamp, Adjustable rider foot-pegs in billet aluminium, Sport style handgrips, GPS module |
Provided equipment | Passenger seat and footpegs kit, Racing tank cap in billet aluminium, Removing license plate holder kit, Mirror hole covers in billet aluminium, Clutch cover protector in carbon fibre, Customized bike cover, Certificate of authenticity, Customized box for additional equipment shipment |
Ready for | Ducati Multimedia System (DMS), anti-theft |
Warranty | 24 months unlimited mileage |
Maintenance service intervals | 12,000 km / 7,500 mi, 12 months |
Valve clearance check | 24,000 km / 15,000 mi |
Standard | Euro 5 |
Co2 emissions | 139 g/km |
Consumption | 6.0 l / 1.59 gal per 100 km |
Emission notes | Only for countries where Euro 5 standard applies |
