990 Duke

990 Duke

KTM

Torque103 Nm / 76 lb-ft
Transmission6-speed
Battery capacity10 Ah
CoolingLiquid cooled with water/oil heat exchanger
Power in KW90.5 kW / 121.4 hp
StarterElectric starter
Stroke70.4 mm / 2.77 "
Bore92.5 mm / 3.64 "
ClutchPASC™ antihopping clutch, mechanically operated
CO2 emissions110 g/km
Compression ratio13.5
Displacement947 cm³ / 57.78 in³
EMSBosch EMS with RBW
Design2-cylinder, 4-stroke, parallel twin
Fuel consumption4.7 l/100 km / 1.24 gal/100 miles
Fuel-mixture generationDKK Dellorto (Throttle body 46 mm / 1.81 ")
LubricationForced oil lubrication with 2 oil pumps
Weight (without fuel)179 kg / 394.6 lbs
Wet weight~ 193.8 kg / 427.3 lbs
Tank capacity (approx.)14.8 l / 3.9 gal
Wheelbase1476 mm / 58.11 "
ABSBosch 9.3 MP Two Channel (Supermoto ABS)
Front brake disc diameter300 mm / 11.81 "
Rear brake disc diameter240 mm / 9.45 "
Front brake2x radially mounted 4 piston caliper
Rear brakeSingle-piston floating calliper, brake disc
Chain520 X-Ring
Frame designChromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Front suspensionWP APEX 43
Ground clearance195 mm / 7.68 "
HandlebarAluminium, tapered Ø 28/22 mm
Rear suspensionWP APEX - Monoshock
Seat height825 mm / 32.48 "
SilencerStainless steel primary and secondary silencer
Steering head angle65.8 °
Rear subframe designAluminium, powder-coated
Suspension travel (front)140 mm / 5.51 "
Suspension travel (rear)150 mm / 5.91 "
WheelsCast aluminium wheels
