Triumph
Type | Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin |
Capacity | 900 cc |
Bore | 84.6 mm / 3.33 in |
Stroke | 80 mm / 3.15 in |
Compression | 11.0:1 |
Max power | 64.1 HP / 47.8 kW @ 7250 rpm |
Max torque | 59 ft-lb / 80 Nm @ 3250 rpm |
System | Multipoint sequential electronic fuel injection |
Exhaust | Brushed stainless steel 2 into 2 exhaust system with twin high-level brushed stainless steel silencers |
Final drive | O ring chain |
Clutch | Wet, multi-plate torque assist clutch |
Gearbox | 5 speed |
Frame | Tubular steel, with twin cradles |
Swingarm | Twin-sided steel fabrication |
Front wheel | Spoked steel rims, 19’’ x 2.5’’ |
Rear wheel | Spoked steel rims, 17’’ x 4.25’’ |
Front tire | 100/90-19 Metzeler Tourance |
Rear tire | 150/70 R17 Metzeler Tourance |
Front suspension | Ø41mm forks with cartridge damping, 120 mm / 4.72 in travel |
Rear suspension | Twin shocks with adjustable preload, 120 mm / 4.72 in rear wheel travel |
Front brakes | 310 mm / 12.2 in floating disc, Brembo 4-piston fixed axial caliper, ABS |
Rear brakes | 255 mm / 10.04 in disc, Nissin 2-piston floating caliper, ABS |
Instrument display and functions | Analogue speedometer with LCD multi-functional display |
Width handlebars | 835 mm / 32.87 in |
Height without mirror | 1180 mm / 46.5 in |
Seat height | 790 mm / 31.1 in |
Wheelbase | 1445 mm / 56.9 in |
Rake | 25.6 º |
Trail | 109 mm / 4.29 in |
Tank capacity | 12 litres / 3.17 US gal |
Wet weight | 492 lbs / 223 kg |
Fuel consumption | 54.7 mpg / 4.3 L/100 km |
Co2 figures | 99 g/km EURO 5 CO2 emissions |
