1290 Super Adventure S

1290 Super Adventure S

KTM

Torque138 Nm / 101.7 lb-ft
Transmission6-speed
CoolingLiquid cooled
Power in kw118 kW / 158.3 hp
StarterElectric starter
Stroke71 mm / 2.8 in
Bore108 mm / 4.25 in
ClutchPASC™ slipper clutch, hydraulically actuated
Co2 emissions125 g/km
Compression ratio13.1
Displacement1301 cm³ / 79.4 in³
EmsKeihin EMS with RBW and cruise control, double ignition
Design2-cylinder, 4-stroke, V 75°
Fuel consumption5.7 l/100 km / 41.3 mpg
Fuel mixture generationKeihin EFI (throttle body 52 mm)
LubricationForced oil lubrication with 3 oil pumps
Weight without fuel227 kg / 500.4 lbs
Tank capacity23 l / 6.1 gal
Wet weight~ 250 kg / 551.2 lbs
Wheelbase1557 mm / 61.3 in
AbsBosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode)
Front brake disc diameter320 mm / 12.6 in
Rear brake disc diameter267 mm / 10.5 in
Chain525 X-Ring
Dry weight220 kg / 485 lbs
Frame designChrome-moly tubular space frame, powder-coated
Front suspensionWP SAT (semi-active technology) Upside-Down Ø 48 mm
Ground clearance223 mm / 8.8 in
HandlebarAluminium, tapered Ø 28/22 mm
Rear suspensionWP SAT (semi-active technology) shock absorber
Seat height849/869 mm / 33.4/34.2 in
SilencerStainless steel primary and secondary silencer with two catalytic converters
Steering head angle65.3°
Rear subframe designAluminium, powder-coated
Suspension travel front200 mm / 7.87 in
Suspension travel rear200 mm / 7.87 in
WheelsCast aluminium wheels
