Yamaha
Engine type | 4-stroke, Liquid-cooled, DOHC, 4-valves, 3-Cylinder |
Displacement | 890 cc |
Bore x stroke | 78.0 mm / 3.07 in × 62.1 mm / 2.44 in |
Compression ratio | 11.5 : 1 |
Maximum power | 87.5 kW / 117.3 hp @ 10,000 rpm |
Limited power version | A2 Version restricted - 35.0 kW / 46.9 hp @ 6,000 rpm, A2 Version unrestricted - 70.0 kW / 93.8 hp @ 9,000 rpm |
Maximum Torque | 93.0 Nm / 68.60 lb-ft @ 7,000 rpm |
Lubrication system | Wet sump |
Clutch Type | Wet, Multiple Disc |
Ignition system | TCI |
Starter system | Electric |
Transmission system | Constant Mesh, 6-speed |
Final transmission | Chain |
Fuel consumption | 5 L/100 km / 47 mpg |
CO2 emission | 116 g/km |
Carburettor | Electronic Fuel Injection |
Frame | Diamond |
Caster Angle | 25°00' |
Trail | 108 mm / 4.25 in |
Front suspension system | Telescopic fork |
Rear suspension system | (Link type suspension), Swingarm |
Front travel | 130 mm / 5.12 in |
Rear Travel | 137 mm / 5.39 in |
Front brake | 298 mm / 11.73 in |
Rear brake | 245 mm / 9.65 in |
Front tyre | 120/70 ZR17M/C (58W) Tubeless |
Rear tyre | 180/55 ZR17M/C (73W) Tubeless |
Overall length | 2,155 mm / 84.84 in |
Overall width | 860 mm / 33.86 in |
Overall height | 1,155 mm / 45.47 in |
Seat height | 810 mm / 31.89 in |
Wheel base | 1,495 mm / 58.86 in |
Minimum ground clearance | 140 mm / 5.51 in |
Wet weight (including full oil and fuel tank) | 193 kg / 425.49 lb |
Fuel tank capacity | 14 L / 3.7 gal |
Oil tank capacity | 3.50 L / 0.92 gal |
