CRF1100L Africa Twin Adventure Sports

CRF1100L Africa Twin Adventure Sports

MSRP in US [2024]: 17,599$
MSRP in EU [2024]: 18,490

Honda

TypeLiquid-cooled OHC 4-stroke 8-valve Parallel Twin with 270° crank and uni-cam
Displacement1084 cc
Bore Stroke92 mm / 3.62" x 81.5 mm / 3.21"
Compression Ratio10.5:1
Max Power Output75 kW / 100.6 hp at 7,500 rpm
Max Torque112 Nm / 82.6 lb-ft at 5,500 rpm
Noise LevelMT: Lurban 75.0 dB, Lwot 80.5 dB, DCT: Lurban 75.4 dB, Lwot 80.4 dB
Oil CapacityMT: 4.8 l / 1.27 gal, DCT: 5.2 l / 1.37 gal
CarburationPGM-FI
Fuel Tank Capacity24.8 l / 6.55 gal
CO2 Emissions114 g/km
Fuel ConsumptionMT: 20.5 km/l [4.9 l/100km] / 48.2 mpg, DCT: 20.5 km/l [4.9 l/100km] / 48.2 mpg
Battery Capacity12V-6Ah Li-ion
Clutch TypeMT: Wet, multiplate with coil springs, Aluminium Cam Assist and Slipper clutch, DCT: 2 wet, multiplate clutches with coil springs
Transmission Type6 speed manual, 6 speed DCT
Final DriveO-ring sealed chain
Frame TypeSemi double cradle
Dimensions LWH2305 mm / 90.75" x 960 mm / 37.8" x 1475 mm / 58.07"
Wheelbase1570 mm / 61.81"
Caster Angle27.5°
Trail106 mm / 4.17"
Seat Height835 mm / 32.87", 855 mm / 33.66", Low seat option: 795 mm / 31.3"
Ground Clearance220 mm / 8.66"
Kerb WeightMT: 243 kg / 535.72 lbs, DCT: 253 kg / 557.77 lbs
Turning Radius2.6 m / 8.53 ft
Suspension FrontSHOWA Telescopic inverted fork with 45 mm inner tube, electronic control unit (SHOWA EERATM), compression and rebound damping adjustments, 210 mm / 8.27" stroke
Suspension RearMonoblock aluminium swing arm with Pro-Link, SHOWA gas-charged damper, hydraulic remote control preload adjuster, electronic control unit (SHOWA EERATM), compression and rebound damping adjustments, 200 mm / 7.87" rear wheel travel
Wheels Front19M/C x MT2.50 wire spoke with aluminium rim
Wheels Rear18M/C x MT4.00 wire spoke with aluminium rim
Tyres Front110/80-R19M/C 59V (Tubeless type) Bridgestone Battlax Adventure A41
Tyres Rear150/70-R18M/C 70H (Tubeless type) Bridgestone Battlax Adventure A41
ABS System Type2 channel with IMU, Selectable ABS MODE with ON road and OFF road
Brakes Front310 mm / 12.2" dual wave floating hydraulic disc with aluminium hub, radial fit 4-piston calipers, sintered metal pads
Brakes Rear256 mm / 10.08" wave hydraulic disc with 2-piston caliper, sintered metal pads, 2-channel with rear ABS off mode
InstrumentsLCD Meter, TFT 6.5 inch touch panel multi information display
HeadlightLED
TaillightLED
ConnectivityBluetooth and Apple CarPlay, Android Auto (wired)
USBYes
12V SocketYes
Auto Winker CancelYes
QuickshifterOptional (MT only)
Security SystemImmobiliser
Cruise ControlYes
Cornering LightsYes
Additional FeaturesEmergency stop signal, 6 axis IMU, HSTC, Wheelie Control
