CMX1100 Rebel

CMX1100 Rebel

Honda

Engine typeSOHC liquid-cooled 4-stroke 8-valve parallel twin with 270° crank and Uni-cam.
Engine displacement1084cc
Engine bore stroke92mm / 3.62" x 81.5mm / 3.21"
Engine compression ratio10.1:1
Engine max power output64kW / 85.8 hp at 7,000rpm
Engine max torque98Nm / 72.3 lb-ft at 4,750rpm
Engine oil capacity4.8L / 1.27 gal, 4.3L / 1.14 gal (DCT)
Fuel system carburationPGM-FI electronic fuel injection
Fuel system tank capacity13.6L / 3.59 gal
Fuel system fuel consumption20.4km/l (4.9L/100km)
Fuel system noise levelsLurban 75.7dB, Lwot 79.6dB - MT; Lurban 75.5dB, Lwot 79.9dB - DCT
Fuel system co2 emissions114g/km – MT and DCT
Electrical starterElectric
Electrical battery capacity12V/11.2AH
Electrical acg output0.419kW / 0.56 hp
Drivetrain clutch typeMT: Wet multiplate clutch, DCT: Wet multiplate hydraulic 2-clutch
Drivetrain transmission typeMT: 6-speed Manual Transmission, DCT: 6-speed Dual Clutch Transmission
Drivetrain final driveChain
Frame typeDiamond
Chassis dimensions2240mm / 88.19" x 853mm / 33.58" x 1115mm / 43.9" - MT; 2240mm / 88.19" x 834mm / 32.83" x 1115mm / 43.9" - DCT
Chassis wheelbase1520mm / 59.84"
Chassis caster angle fork angle28° / 30°
Chassis trail110mm / 4.33"
Chassis seat height700mm / 27.56"
Chassis ground clearance120mm / 4.72"
Chassis kerb weightMT: 223kg / 491.6 lbs, DCT: 233kg / 513.7 lbs, CMX1100T Rebel - MT: 238kg / 524.7 lbs, DCT: 248kg / 546.7 lbs
Suspension type frontPreload adjustable 43mm cartridge style
Suspension type rearPreload adjustable twin piggyback rear shock
Wheels type frontMulti-spoke cast aluminium
Wheels type rearMulti-spoke cast aluminium
Wheels rim size frontMT3.50
Wheels rim size rearMT5.00
Wheels tyres front130/70B18 M/C
Wheels tyres rear180/65B16 M/C
Brakes abs system type2-channel ABS
Brakes type frontRadial mounted monoblock four-piston brake caliper, 330mm floating single disc
Brakes type rearSingle piston caliper, 256mm single disc
Instruments instrumentsOffset 120mm negative LCD instrument display, USB-C charger
Instruments security systemHISS
Instruments headlightLED
Instruments taillightLED
