Torquepedia
200 Duke

200 Duke

KTM

Torque19.5 Nm / 14.4 lb-ft
Transmission6-speed
Battery capacity8 Ah
CoolingLiquid cooled
Power in KW18.4 kW / 24.7 hp
StarterElectric starter
Stroke49 mm / 1.93 "
Bore72 mm / 2.83 "
ClutchWet multi-disc clutch, mechanically actuated
Compression ratio11.5
Displacement199.5 cm³ / 12.17 in³
EMSBosch EMS
Design1-cylinder, 4-stroke engine
Fuel-mixture generationBosch EFI (throttle valve 38 mm / 1.5 ")
LubricationWet sump
Weight (without fuel)146 kg / 321.9 lbs
Wet weight~ 159.4 kg / 351 lbs
Tank capacity (approx.)13.4 l / 3.54 gal
Wheelbase1357 mm / 53.43 "
Front brake disc diameter300 mm / 11.81 "
Rear brake disc diameter230 mm / 9.06 "
Front brakeFour-piston radial fixed calliper, brake disc
Rear brakeSingle-piston floating calliper, brake disc
Chain520 X-Ring
Frame designSteel trellis frame, powder coated
Front suspensionWP APEX 43
Ground clearance147 mm / 5.79 "
HandlebarSteel, tapered Ø 26/22 mm
Seat height830 mm / 32.68 "
SilencerStainless steel primary and aluminium secondary silencer
Steering head angle65 °
Rear subframe designSteel trellis frame, powder coated
Suspension travel (front)142 mm / 5.59 "
Suspension travel (rear)150 mm / 5.91 "
WheelsCast aluminium wheels
