Honda
Engine type | Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder. EURO5 compliant |
Engine displacement | 745cc |
Bore and stroke | 77mm / 3.03" x 80mm / 3.15" |
Compression ratio | 10.7:1 |
Max power output | 43.1kW / 57.8 hp @ 6,750rpm |
Max torque | 69Nm / 50.9 lb-ft @ 4,750rpm |
Oil capacity | 4L / 1.06 gal |
Noise level l wot | 77 dB |
Noise level l urban | 72 dB |
Carburation | PGM-FI electronic fuel injection |
Fuel tank capacity | 14.1L / 3.72 gal |
Fuel consumption mt | 28.3 km/l |
Fuel consumption dct | 28.3 km/l |
Starter | Electric |
Battery capacity | 12V/11AH |
Clutch type mt | Wet multiplate clutch |
Clutch type dct | Wet multiplate hydraulic 2-clutch |
Transmission type mt | 6-speed Manual Transmission |
Transmission type dct | 6-speed Dual Clutch Transmission |
Final drive | Chain |
Frame type | Diamond; steel pipe |
Dimensions | 2210mm / 87.01" x 846mm / 33.31" x 1330mm / 52.36" |
Wheelbase mt | 1535mm / 60.43" |
Wheelbase dct | 1535mm / 60.43" |
Caster angle | 27° |
Trail | 110mm / 4.33" |
Seat height | 800mm / 31.50" |
Ground clearance | 145mm / 5.71" |
Kerb weight mt | 214kg / 471.79 lbs |
Kerb weight dct | 224kg / 493.84 lbs |
Suspension type front | 41mm telescopic fork, 120mm stroke |
Suspension type rear | Monoshock damper, Pro-Link swingarm, 120mm travel |
Wheels type front | Multi-spoke cast aluminium |
Wheels type rear | Multi-spoke cast aluminium |
Rim size front | 17M/C x MT3.50 |
Rim size rear | 17M/C x MT4.50 |
Tyres front | 120/70-ZR17M/C (58W) |
Tyres rear | 160/60-ZR17M/C (69W) |
Abs system type | 2-channel ABS |
Brakes type front | 320mm / 12.6" single wavy hydraulic disc with 2-piston caliper and sintered metal pads |
Brakes type rear | 240mm / 9.45" single wavy hydraulic disc with single-piston caliper and resin mold pads |
Instruments | Digital speedometer, digital bar-type tachometer, clock, bar-type fuel meter, two trip meters, gear position indicator, ‘instant’ and ‘average’ fuel consumption, coolant temperature warning light |
Security system | HISS |
Headlight | LED |
Taillight | LED |
