GSX-S750

GSX-S750

Suzuki

Overall length2,125 mm (83.7 in)
Overall width785 mm (30.9 in)
Overall height1,055 mm (41.5 in)
Wheelbase1,455 mm (57.3 in)
Ground clearance135 mm (5.3 in)
Seat height820 mm (32.3 in)
Curb mass213 kg (469 lbs)
Engine type4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore stroke72.0 mm × 46.0 mm (2.8 in × 1.8 in)
Displacement749 cm3 (45.7 cu.in)
Compression ratio12.3 : 1
Fuel systemFuel injection
Starter systemElectric
Lubrication systemWet sump
Transmission6-speed constant mesh
Primary reduction ratio1.857 (78 / 42)
Final reduction ratio2.529 (43 / 17)
Front suspensionInverted telescopic, coil spring oil damped
Rear suspensionLink type, coil spring, oil damped
Rake trail25° / 100 mm (3.9 in)
Front brakeDisc, twin
Rear brakeDisc
Front tire size120/70ZR17M/C (58W), tubeless
Rear tire size180/55ZR17M/C (73W), tubeless
Ignition systemElectronic ignition (Transistorized)
Fuel tank capacity16.0 L (4.2/3.5 US/Imp gal)
Oil capacity overhaul3.9 L (4.1/3.4 US/lmp qt)
