Triumph
Type | Liquid cooled, inline 3-cylinder, 12 valve, DOHC, 240° Firing order |
Capacity | 660 cc |
Bore | 74.04 mm / 2.91 in |
Stroke | 51.1 mm / 2.01 in |
Compression | 12.05:1 |
Max power ec | 95 PS / 95 hp / 69.8 kW @ 11,250 rpm |
Max torque ec | 50.88 lb-ft / 69 Nm @ 8,250 rpm |
System | Multipoint sequential electronic fuel injection with electronic throttle control |
Exhaust | Stainless steel 3 into 1 header system with low single sided stainless steel silencer |
Final drive | X-ring chain |
Clutch | Wet, multi-plate, slip and assist |
Gearbox | 6-speed |
Frame | Tubular steel perimeter frame |
Swingarm | Twin-sided, fabricated steel |
Front wheel | Cast aluminium alloy 5 spoke, 17 x 3.5 in |
Rear wheel | Cast aluminium alloy 5 spoke, 17 x 5.5 in |
Front tire | 120/70 ZR 17 |
Rear tire | 180/55 ZR 17 |
Front suspension | Showa 41mm / 1.61 in upside down Separate Function Forks - Big Piston (SFF-BP), 110 mm / 4.33 in wheel travel |
Rear suspension | Showa monoshock RSU, with preload adjustment, 130 mm / 5.11 in wheel travel |
Front brakes | Twin 310 mm / 12.20 in floating discs, 4 piston radial calipers, ABS |
Rear brakes | Single 220 mm / 8.66 in fixed disc, single piston sliding caliper, ABS |
Instrument display and functions | Multi-function instruments with color TFT screen |
Width handlebars | 736 mm / 28.97 in |
Height without mirror | 1145.2 mm / 45.08 in |
Seat height | 810 mm / 31.88 in |
Wheelbase | 1425.6 mm / 56.12 in |
Rake | 23.8° |
Trail | 82.3 mm / 3.2 in |
Tank capacity | 14 L / 3.7 US gal |
Wet weight | 443 lb / 201 kg |
Service interval | 10,000 miles / 16,000 km or 12 months, whichever comes first |
