BMW
Design | Two-cylinder, air-/fluid-cooled, four-stroke boxer engine with two overhead spur-gear driven camshafts, one balancer shaft and BMW ShiftCam variable intake camshaft control |
Bore stroke | 102.5 mm x 76 mm / 4.04" x 2.99" |
Capacity | 1,254 ccm |
Nominal capacity | 100 kW / 136 hp at 7,750 rpm |
Max torque | 143 Nm at 6,250 rpm / 105.4 lb-ft |
Compression ratio | 12.5:1 |
Fuel preparation | Electronic intake pipe fuel injection, digital engine control: BMS-O with e-gas |
Emission control | Closed-loop three-way catalytic converter, compliant with EU-5 emission standard |
Maximum speed | Over 200 km/h / 124 mph |
Consumption wmtc | 4.75 L/100 km / 49.5 mpg |
Co2 emissions wmtc | 110 g/km |
Fuel type | Super petrol unleaded, octane number 95 (ROZ), adaptation through engine control (91 to 98 ROZ) |
Alternator | Three-phase generator with 508-watt nominal capacity |
Battery | 12 V / 11.8 Ah, maintenance-free |
Ecall | Intelligent Emergency Call |
Clutch | Wet clutch with an anti-hopping function, hydraulic activation |
Gears | Six-speed helical synchromesh gearbox |
Secondary drive | Drive shaft |
Frame | Two-part frame concept consisting of a main frame and a rear frame bolted to it, with a co-supporting engine |
Front suspension | BMW Motorrad Telelever, central spring strut, standard diameter Ø 37 mm / Ø 1.46" |
Rear suspension | Cast aluminium single-sided swinging arm with BMW Motorrad Paralever, WAD spring strut, spring preload continuously and hydraulically adjustable via adjuster knob, adjustable rebound-stage damping via adjuster knob |
Spring travel front rear | 120 mm / 136 mm / 4.72" / 5.35" |
Wheelbase | 1,485 mm / 58.46" |
Castor | 116 mm / 4.57" |
Steering head angle | 64.1° |
Wheels | Cast aluminium |
Rim front | 3.50" x 17" |
Rim rear | 5.50" x 17" |
Tyre front | 120/70 ZR17 |
Tyre rear | 180/55 ZR17 |
Brake front | Twin disc brake, floating discs, Ø 320 mm / Ø 12.6", four-piston radial brake callipers |
Brake rear | Single disc brake, Ø 276 mm / Ø 10.87", double-piston floating calliper |
Abs | BMW Motorrad full integral ABS Pro (full integral braking, lean optimised) |
Seat height unladen | 805 mm / 825 mm / 31.69" / 32.48" (SE high seat: 830 mm / 850 mm / 32.68" / 33.46", low seat: 760 mm / 780 mm / 29.92" / 30.71") |
Rider step length unladen | 1,810 mm / 1,850 mm / 71.26" / 72.83" (SE high seat: 1,875 mm / 1,915 mm / 73.82" / 75.39", SE low seat: 1,740 mm / 1,780 mm / 68.50" / 70.08") |
Usable tank capacity | 25 L / 6.6 gal |
Reserve | Approx. 4 L / 1.1 gal |
Length | 2,222 mm / 87.48" (with number plate carrier) |
Height above windscreen | Min. 1,460 mm / 57.48", max. 1,570 mm / 61.81" (Style Sport: min. 1,360 mm / 53.54", max. 1,480 mm / 58.27") |
Width including mirrors | 985 mm / 38.78" |
Breadth including boot | 990 mm / 38.98" |
Vehicle kerb weight fully fuelled | 279 kg / 615.09 lbs |
Max permitted weight | 505 kg / 1,113.33 lbs |
Max load | 226 kg / 498.24 lbs |
