Honda
Displacement | 782.0 ccm (47.72 cubic inches) |
Engine type | V4, four-stroke |
Engine details | 90 degree V-4 |
Power output | 107.0 HP (78.1 kW) @ 10250 RPM |
Torque | 75.1 Nm (7.7 kgf-m or 55.4 ft.lbs) @ 8500 RPM |
Compression | 11.8:1 |
Bore x stroke | 72.0 x 48.0 mm (2.8 x 1.9 inches) |
Valves per cylinder | 4 |
Fuel system | Injection. PGM-FI electronic fuel injection |
Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
Ignition | Computer-controlled digital transistorised with electronic advance |
Cooling system | Liquid |
Gearbox | 6-speed |
Transmission type | Chain (final drive) |
Clutch | Wet, multiplate with coil springs |
Driveline | O-ring sealed chain |
Frame type | Diamond; triple-box-section aluminium twin-spar. Swing arm: 548mm |
Trail | 95 mm (3.7 inches) |
Front suspension | 43mm HMAS cartridge-type telescopic fork with stepless preload and ten DF adjustment, 108mm axle travel |
Front wheel travel | 233 mm (9.2 inches) |
Rear suspension | Pro-Link with gas-charged HMAS damper, 7-step (stepless remote-controlled hydraulic) preload and stepless rebound damping adjustment, 120mm axle travel |
Rear wheel travel | 233 mm (9.2 inches) |
Front tire | 120/70-ZR17 |
Rear tire | 180/55-ZR17 |
Front brakes | Double disc. ABS. Floating discs. Hydraulic. Four-piston calipers. |
Front brake diameter | 310 mm (12.2 inches) |
Rear brakes | Single disc. ABS. Hydraulic. Two-piston calipers. |
Rear brake diameter | 256 mm (10.1 inches) |
Dry weight | 217.0 kg (478.4 pounds) |
Weight incl oil gas etc | 239.0 kg (526.9 pounds) |
Power weight ratio | 0.4931 HP/kg |
Seat height | 805 mm (31.7 inches) |
Overall height | 1203 mm (47.4 inches) |
Overall length | 2134 mm (84.0 inches) |
Overall width | 748 mm (29.4 inches) |
Ground clearance | 126 mm (5.0 inches) |
Wheelbase | 1460 mm (57.5 inches) |
Fuel capacity | 21.50 litres (5.68 US gallons) |
Oil capacity | 3.80 litres (4.02 US quarts) |
