MT-07 Pure 35kW
Yamaha
| Engine type | 2-Cylinder, 4-stroke, Liquid-cooled, DOHC, 4-valves |
| Displacement | 689 cc |
| Bore x stroke | 80,0 mm / 3.15 " x 68,6 mm / 2.70 " |
| Compression ratio | 11,5 : 1 |
| Maximum power | 35,0 kW / 47.6 PS @ 7,750 rpm |
| Maximum torque | 62,0 Nm / 45.7 lb-ft @ 4,250 rpm |
| Lubrication system | Wet sump |
| Clutch type | Wet, Multiple Disc |
| Ignition system | TCI |
| Starter system | Electric |
| Transmission system | Constant Mesh, 6-speed |
| Final transmission | Chain |
| Fuel consumption | 4,2 L/100 km / 56.0 mpg |
| Co2 emission | 98 g/km |
| Carburettor | Electronic Fuel Injection |
| Frame | Diamond |
| Caster angle | 24º50' |
| Trail | 90 mm / 3.54 " |
| Front suspension system | Telescopic forks |
| Rear suspension system | Swingarm, (Link type suspension) |
| Front travel | 130 mm / 5.12 " |
| Rear travel | 130 mm / 5.12 " |
| Front brake | Hydraulic dual disc, Ø 298 mm / 11.73 " |
| Rear brake | Hydraulic single disc, Ø 245 mm / 9.65 " |
| Front tyre | 120/70 ZR17M/C (58W) Tubeless |
| Rear tyre | 180/55 ZR17M/C (73W) Tubeless |
| Overall length | 2.085 mm / 82.09 " |
| Overall width | 780 mm / 30.71 " |
| Overall height | 1.105 mm / 43.50 " |
| Seat height | 805 mm / 31.69 " |
| Wheel base | 1.400 mm / 55.12 " |
| Minimum ground clearance | 140 mm / 5.51 " |
| Wet weight | 184 kg / 405.65 lbs |
| Fuel tank capacity | 14 L / 3.7 gal |
| Oil tank capacity | 3,0 L / 0.79 gal |
